WD-SJ602 Sintering flux for submerged arc welding


WD-SJ602 is a fluoroalkali type alkaline sintering flux with an alkalinity of about 2.5. The appearance is 10-60 mesh (2.0-0.28mm) milky yellow spherical particles.

Subclassification:

· Hard Surfacing


电话

Enquiry hotline:

Contact us
  • Product description
    • Commodity name: WD-SJ602 Sintering flux for submerged arc welding
    • Commodity ID: 20230112004

    WD-SJ602 is a fluoroalkali type alkaline sintering flux with an alkalinity of about 2.5. The appearance is 10-60 mesh (2.0-0.28mm) milky yellow spherical particles.

    Standards:

    GB/T17854  AWSA5.9M  ER2209



    Introduction:

    WD-SJ602 is a fluoroalkali type alkaline sintering flux with an alkalinity of about 2.5. The appearance is 10-60 mesh (2.0-0.28mm) milky yellow spherical particles. The flux is welded with ER2209 wire, the deposited metal is pure and the burned elements are less; it has high tensile strength and yield strength; the experimental data meets the American standard (AWS); it has relatively high ferrite content; the slag shell is buckled after welding; the slag is easily removed from the narrow gap; the weld seam is beautifully formed; the arc burning is stable; it has good resistance to moisture absorption, with high particle strength, small loose packing density and low flux consumption during welding.



    Applications:
    It can be used for welding petrochemical equipment, seawater and wastewater treatment equipment, oil and gas pipelines, and ships for chemical industry.



    Flux chemical composition reference value(%):

    SiO2+TiO2

    CaO+MgO

    Al203+MnO

    CaF2

    S

    P

    15.2

    35.2

    29.8

    19.6

    ≤0.06

    ≤0.08


    Reference values for mechanical properties of molten metal:

    Mating wire

    Yield strength
    (MPa)

    Tensile strength
    (MPa)

    Elongation
    (%)

    KV2 (J)

    -20°C

    ER2209

    σ0.2560

    σ1.0600

    740

    30

    75


    Notice:

    1. The flux shall be baked at 300-350°C for 2 hours before use.

    2. Rust, oil, water and other impurities should be removed from the welded parts before welding.
